For nearly six decades, the Ruger 10/22 has held a prominent place in the world of shooting sports.
But what makes it so special, you ask? It’s the fusion of reliability, affordability, and customization that sets this semi-automatic rifle apart from its competitors.
Think of threaded barrels as the ‘extra spice’ in your shooting experience.
Say goodbye to the limitations of inferior barrels and embrace the reliability and longevity offered by the Faxon Rimfire barrel.
Whether you’re engaged in competitive shooting, hunting, or plinking, this barrel’s robust design ensures it stands up to the test, providing you with consistent performance and peace of mind.
Features of a Ruger 10/22 Threaded Barrel
Ruger 10/22 threaded barrels from Faxon come in various lengths, ranging from 6 to 16 inches; 16 inches being the most common. These barrels, constructed from high-quality steel, guarantee durability and robustness.
The thread pitch on the 10/22 barrel are 1/2″-28 TPI (Threads Per Inch), the most common threading for .22 caliber firearms. This universal specification allows for a wide range of attachments.
The 1:16 twist rate is often considered ideal for .22LR (.22 Long Rifle) cartridges due to several factors. Here are a few reasons why this twist rate is commonly favored.
Why is the 1:16 twist rate the best for 22LR
Stability: The primary purpose of barrel rifling is to impart a stabilizing spin to the bullet, improving accuracy and consistency. The 1:16 twist rate effectively stabilizes .22LR bullets, allowing them to maintain a stable flight path over short to medium distances.
Bullet Length and Weight: The .22LR bullet is fairly lightweight, usually around 40 grains. These bullets are relatively short compared to heavier projectiles used in larger calibers. The 1:16 twist rate is optimized for stabilizing lighter and shorter bullets, allowing them to achieve greater accuracy.
Muzzle Velocity: .22LR ammunition is known for its relatively low muzzle velocities compared to other cartridges. The 1:16 twist rate complements the lower velocities of .22LR by providing sufficient spin stabilization without over-stabilizing the bullet. Over-stabilization can negatively impact accuracy, so the 1:16 twist rate strikes a balance.
Common Industry Standard: Over time, the 1:16 twist rate has become the standard for .22LR rifles and handguns. This consistency allows manufacturers to produce firearms with interchangeable barrels and ensures compatibility with a wide range of commercially available ammunition.
It’s important to note that while the 1:16 twist rate is widely regarded as effective for .22LR, there can be variations based on specific bullet designs, barrel lengths, and shooting conditions. Some firearms may have different twist rates optimized for particular .22LR bullet weights or styles, but the 1:16 twist rate generally offers a good balance of accuracy and stability for most .22LR ammunition.
Ruger 10/22 Threaded Barrels By Faxon Firearms
The “Faxon Rimfire” line of barrels, like all Faxon Barrels, is manufactured internally at our facility in Greater Cincinnati. We start with raw bar stock and employ the same stringent testing and quality control measures that have established Faxon AR and pistol barrels as favorites in the market.
These particular barrels are crafted from 416-R stainless steel, which is renowned for its durability and corrosion resistance. They feature a 6 Groove Rifling configuration with a 1:16 twist rate, ensuring optimal accuracy and stability for your rimfire firearms. Additionally, a Recessed Target Crown is incorporated into the design to enhance the barrel’s precision.
To guarantee exceptional performance, all Faxon 10/22 barrels undergo Magnetic Particle Inspection (MPI), a non-destructive testing method that detects potential flaws or defects. This inspection process helps ensure that only barrels meeting their strict quality standards are approved for use.
As for the finishing options, Faxon 10/22 threaded barrels are available in either Salt Bath Nitride or Physical Vapor Deposition (PVD) finishes. Salt Bath Nitride provides superior corrosion resistance and enhances the barrel’s hardness, while PVD offers a durable and attractive coating.
When it comes to profiles, they offer a variety of options to suit different preferences and shooting styles. You can choose from straight-fluted, pencil, flame-fluted, bull barrel – flame-fluted, and bull barrel – straight-fluted profiles. Each profile has its own unique aesthetic and performance characteristics, allowing you to customize your 10/22 rifle to your liking.
Lastly, Faxon backs all 10/22 threaded barrels with the Faxon Lifetime Guarantee. This means that they stand behind the quality and craftsmanship of their barrels, offering you peace of mind and assurance in your purchase.
Faxon Rimfire barrels are meticulously crafted using high-quality materials and rigorous testing procedures. With their excellent features, finishes, and profile options, these barrels are designed to deliver exceptional performance and reliability.
Faxon Rimfire 6″ Straight Fluted Barrel for 10/22
Enhance the accuracy and functionality of your Ruger 10/22 rifle with the Faxon Rimfire 6″ Straight Fluted Barrel. Designed for discerning shooters, this barrel is meticulously crafted to deliver unrivaled precision and performance. Experience a new level of shooting satisfaction with its cutting-edge features.
Crafted with meticulous attention to detail, the Faxon Rimfire 6″ Straight Fluted Barrel for 10/22 is the result of relentless dedication to quality. Constructed from premium materials, this barrel ensures exceptional durability, allowing you to enjoy its benefits for years to come. Its seamless integration with your Ruger 10/22 guarantees a reliable and seamless shooting experience.
Specs
- Barrel Caliber: .22 LR
- Barrel Chamber: .22 LR Sporting
- Barrel Profile: Straight Fluted
- Barrel Material: 416-R Stainless
- Barrel Weight: .78 lbs
- Barrel Length: 6″
- Barrel Twist: 1:16
- Barrel Finish: Salt Bath Nitride
- Rifling: 6 Groove
- Target Crown: Recessed
- Compatibility: 10/22, non-takedown
- Muzzle Thread: 1/2×28
Faxon Rimfire 8.5″ Patented Flame Fluted Barrel for 10/22
Unlock the true potential of your Ruger 10/22 with the Faxon Rimfire 8.5″ Patented Flame Fluted Barrel. Engineered with precision in mind, this barrel is designed to elevate your shooting experience to new heights. Explore the distinct features that make this barrel a must-have for any discerning shooter.
The unique fluting not only adds a touch of visual flair but also enhances the barrel’s performance. By increasing surface area and reducing weight, the flame fluting promotes better heat dissipation, resulting in cooler barrel temperatures during rapid-fire sessions.
Experience exceptional accuracy with the Faxon Rimfire 8.5″ Patented Flame Fluted Barrel. Meticulously crafted to exacting specifications, it ensures consistent shot placement, allowing you to hit your target with unmatched precision.
Specs
- Barrel Caliber: .22 LR
- Barrel Chamber: .22 LR Sporting
- Barrel Profile: Flame Fluted
- Barrel Material: 416-R Stainless
- Barrel Weight: .95 lbs
- Barrel Length: 8.5″
- Barrel Twist: 1:16
- Barrel Finish: Salt Bath Nitride
- Rifling: 6 Groove
- Target Crown: Recessed
- Compatibility: 10/22, non-takedown
- Muzzle Thread: 1/2×28
Faxon Rimfire 10.5″ Straight Fluted Barrel for 10/22
Unleash your shooting potential with the Faxon Rimfire 10.5″ Straight Fluted Barrel for 10/22. Designed to elevate your accuracy to new heights, this high-performance barrel is perfect for precision shooters and avid enthusiasts. Its exceptional craftsmanship ensures consistent and reliable shot placement, making it the ideal choice for those seeking unparalleled accuracy.
Crafted from premium-quality materials, the Faxon Rimfire barrel undergoes meticulous manufacturing processes to deliver exceptional performance. The straight-fluting design not only enhances its visual appeal but also reduces weight without compromising structural integrity. With its precise rifling, this barrel enables better bullet stabilization, resulting in improved shot-to-shot consistency and enhanced accuracy.
Whether you’re a competitive shooter or a recreational marksman, the Faxon Rimfire 10.5″ Straight Fluted Barrel empowers you to hit your targets with pinpoint precision. Experience the thrill of tight groupings and precise shots, giving you the confidence to outperform your competition and reach new levels of shooting mastery.
Specs
- Barrel Caliber: .22 LR
- Barrel Chamber: .22 LR Sporting
- Barrel Profile: Straight Fluted
- Barrel Material: 416-R Stainless
- Barrel Weight: 1.1 lbs
- Barrel Length: 10.5″
- Barrel Twist: 1:16
- Barrel Finish: Salt Bath Nitride
- Rifling: 6 Groove
- Target Crown: Recessed
- Compatibility: 10/22, non-takedown
- Muzzle Thread: 1/2×28
Faxon Rimfire 16″ Straight Fluted 10/22 Barrel
Unleash the true potential of your Ruger 10/22 with the Faxon Rimfire 16″ Straight Fluted Barrel. Engineered to deliver exceptional accuracy and performance, this barrel is designed for precision shooting enthusiasts.
In order to add the distinctive Faxon style to these 10/22 threaded barrels, they have modified three of its highly sought-after barrel designs originally used for the AR platform to suit the Ruger 10/22 platform: Pencil, Straight Fluted, and the exclusive Flame Fluted profile.
With its 16″ length, this barrel provides increased muzzle velocity and improved ballistics. Experience tighter groupings and extended effective range, giving you the edge in any shooting scenario.
Additionally, Faxon threaded 10/22 barrels provide a reduction in weight compared to standard factory barrels designed for the 10/22.
- Standard Factory Barrel: 1.78 lbs
- Faxon Rimfire Pencil Barrels: 1.0 lbs
- Faxon Rimfire Fluted Barrels: 1.4 lbs
Specs
- Barrel Caliber: .22 LR
- Barrel Chamber: .22 LR Sporting
- Barrel Profile: Straight Fluted
- Barrel Material: 416-R Stainless
- Barrel Weight: 1.4 lbs
- Barrel Length: 16″
- Barrel Twist: 1:16
- Barrel Finish: Salt Bath Nitride
- Rifling: 6 Groove
- Target Crown: Recessed
- Compatibility: 10/22, non-takedown
- Taper:
- .912″ after chamber
- .586″ before thread shoulder
- Muzzle Thread: 1/2×28
The Ruger 10/22 threaded barrels offered by Faxon Firearms provide gun enthusiasts with a reliable and versatile upgrade option. These barrels not only enhance the overall performance of the Ruger 10/22 rifle but also offer the convenience of attaching various muzzle devices and suppressors.
Faxon Firearms has demonstrated its commitment to quality and precision with its meticulously crafted threaded barrels. Their attention to detail ensures consistent accuracy and durability, making them a reliable choice for shooters of all skill levels.
The threaded barrels from Faxon Firearms open up a world of possibilities for customization and personalization. Whether it’s for competitive shooting, hunting, or recreational purposes, the ability to easily attach different accessories allows users to adapt their Ruger 10/22 to suit their specific needs.
Furthermore, Faxon Firearms’ reputation for exceptional customer service adds to the overall positive experience of purchasing their products. They prioritize customer satisfaction, providing reliable support and assistance throughout the purchasing and installation process.
Overall, Ruger 10/22 threaded barrels from Faxon Firearms offer a winning combination of performance, versatility, and customer support. With their superior craftsmanship and compatibility with various muzzle devices, these barrels elevate the Ruger 10/22 rifle to new heights.
